Flamma® Fluors

BioActs offers a broad range of Flamma® Fluors dyes equipped with variety of reactive and functional groups, which can cover the full spectral range from UV to NIR with their excellent fluorescence performance. Characteristic features of these superior dyes are strong absorption, high fluorescence quantum yield and high photostability. Flamma® dyes maintain good fluorescence activity and stability after conjugation to biomolecules and allow the detection of low-abundance biological structures with great sensitivity. The dyes are compatible with optical conditions of most of fluorescent equipment and are ideal for any applications in biological studies.

Flamma® Fluors NHS ester

496	552	581		648		675		749	774
Quick link (Cat.#) FSD series EXmax (nm) EMmax (nm) Spectrally similar dyes CWS1001 Flamma® 496 NHS ester 496 520 Alexa488, FITC, Cy2 PWS1122 Flamma® 552 NHS ester 550 564 Alexa555, DyLight549, Cy3, ATTO550 PWS1415 Flamma® 581 NHS ester 581 596 Alexa594, DyLight594 PWS1215 Flamma® 648 NHS ester 648 663 Alexa647, DyLight650, Cy5 PWS1515 Flamma® 675 NHS ester 675 691 Alexa680, DyLight680, Cy5.5, IRDye680LT, CF680 PWS1301 Flamma® 749 NHS ester 749 774 Alexa750, DyLight755, Cy7.5, IRDye750 PWS1603 Flamma® 774 NHS ester 774 800 Cy7.5, DyLight800, IRDye800

Flamma® Fluors Sulfo-NHS ester

496	552	581		648		675		749	774



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
CWSN1001	Flamma® 496 Sulfo-NHS ester	496	520	Alexa488, FITC, Cy2
PWSN1122	Flamma® 552 Sulfo-NHS ester	550	564	Alexa555, DyLight549, Cy3, ATTO550
PWSN1415	Flamma® 581 Sulfo-NHS ester	581	596	Alexa594, DyLight594
PWSN1215	Flamma® 648 Sulfo-NHS ester	648	663	Alexa647, DyLight650, Cy5
PWSN1515	Flamma® 675Sulfo-NHS ester	675	691	Alexa680, DyLight680, Cy5.5, IRDye680LT, CF680
PWSN1301	Flamma® 749 Sulfo-NHS ester	749	774	Alexa750, DyLight755, Cy7.5, IRDye750
PWSN1603	Flamma® 774 Sulfo-NHS ester	774	800	Cy7.5, DyLight800, IRDye800

Flamma® Fluors Vinylsulfone
488	496	552	581	594	648	675	749	774	800



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
CWA1002	Flamma® 488 Vinylsulfone	495	519	Alexa488, Cy2
CWA1001	Flamma® 496 Vinylsulfone	496	520	Alexa488, FAM
PWA1122	Flamma® 552 Vinylsulfone	550	564	Alexa555, DyLight549, Cy3, ATTO550, CF555
PWA1415	Flamma® 581 Vinylsulfone	581	596	Alexa594, DyLight594
KOA1001	Flamma® 594 Vinylsulfone	590	617	Alexa594, DyLight594
PWA1215	Flamma® 648 Vinylsulfone	648	683	Alexa647, DyLight650, Cy5
PWA1515	Flamma® 675 Vinylsulfone	675	691	Alexa680, DyLight680, Cy5.5, IRDye680LT, CF680
PWA1308	Flamma® 749 Vinylsulfone	749	774	Alexa750, DyLight755, Cy7, IRDye750
PWA1603	Flamma® 774 Vinylsulfone	774	795	Cy7.5, CF 770, DyLight 800, IRDye800
POA1803	Flamma® 800 Vinylsulfone	774	789	Cy7.5, DyLight800, IRDye800

Flamma® Fluors Isothiocyanate
496	552	581	648	675	749	774



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
PWI1001	Flamma® 496 Isothiocyanate	494	520	Alexa488, FITC, Cy2
PWI1122	Flamma® 552 Isothiocyanate	550	564	Alexa555, DyLight549, Cy3, ATTO550
PWI1415	Flamma® 581 Isothiocyanate	578	593	Alexa594, DyLight594
KWI1215	Flamma® 648 Isothiocyanate	648	663	Alexa647, DyLight650, Cy5
KWI1515	Flamma® 675 Isothiocyanate	675	691	Alexa680, DyLight680, Cy5.5, IRDye680LT
PWI1308	Flamma® 749 Isothiocyanate	749	774	Alexa750, DyLight755, Cy7.5, IRDye750
PWI1603	Flamma® 774 Isothiocyanate	774	800	Cy7.5, DyLight800, IRDye800

Flamma® Fluors Maleimide
496	552	581	648	675	749	774



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
CWM1001	Flamma® 496 Maleimide	496	520	Alexa488, FAM
CWM1058	Flamma® 552 Maleimide	550	565	Alexa555, DyLight549, Cy3, ATTO550, CF555
KWM1415	Flamma® 581 Maleimide	581	596	Alexa594, DyLight594
KWM1042	Flamma® 648 Maleimide	648	663	Alexa647, DyLight650, Cy5, ATTO 647N, CF647
PWM1415	Flamma® 675 Maleimide	675	691	Alexa680, DyLight680, Cy5.5, IRDye680LT, CF680
PWM1215	Flamma® 749 Maleimide	749	774	Alexa750, DyLight755, Cy7, IRDye750
PWM1515	Flamma® 774 Maleimide	774	806	Cy7.5, DyLight800, IRDye800

Flamma® Fluors Hydrazide
496	552	581	648	675	749	774



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
CWH1001	Flamma® 496 Hydrazide	496	520	Alexa488, FITC, Cy2
PWH1122	Flamma® 552 Hydrazide	550	564	Alexa555, DyLight549, Cy3, ATTO550
KWH1415	Flamma® 581 Hydrazide	578	593	Alexa594, DyLight594
PWH1215	Flamma® 648 Hydrazide	648	663	Alexa647, DyLight650, Cy5
PWH1515	Flamma® 675 Hydrazide	675	691	Alexa680, DyLight680, Cy5.5, IRDye680LT, CF680
PWH1301	Flamma® 749 Hydrazide	749	774	Alexa750, DyLight755, Cy7.5, IRDye750
PWH1603	Flamma® 774 Hydrazide	774	800	Cy7.5, DyLight800, IRDye800

Flamma® Fluors Dichlorotriazine
552	581	648	675	749	774



Quick link (Cat.#)	Series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
PWR2112	Flamma® 552 Dichlorotriazine	550	564	Alexa555, DyLight550, Cy3, ATTO550
KWR2415	Flamma® 581 Dichlorotriazine	578	593	Alexa594, DyLight594
PWR2215	Flamma® 648 Dichlorotriazine	648	667	Alexa647, DyLight650, Cy5
PWR2515	Flamma® 675 Dichlorotriazine	675	691	Alexa680, DyLight680, Cy5.5, IRDye680LT, CF680
PWR2301	Flamma® 749 Dichlorotriazine	749	774	Alexa750, DyLight755, Cy7.5, IRDye750
PWR2603	Flamma® 774 Dichlorotriazine	774	800	DyLight800, Cy7.5, IRDye800, CF770

Flamma® Fluors Carboxylic acid
552	648	675	749	774



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
PWC1101	Flamma® 552 Carboxylic acid	550	565	Alexa555, DyLight549, Cy3, ATTO550
PWC1201	Flamma® 648 Carboxylic acid	648	663	Alexa647, DyLight650, Cy5
PWC1501	Flamma® 675 Carboxylic acid	675	691	Alexa680, DyLight680, Cy5.5, IRDye680LT, CF680
PWC1308	Flamma® 749 Carboxylic acid	749	774	Alexa750, DyLight755, Cy7, IRDye750
PWC1603	Flamma® 774 Carboxylic acid	774	800	Cy7.5, DyLight800, IRDye800

Flamma® Fluors Amine
496	552	581	648	675	749	774



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
CWE1001	Flamma® 496 Amine	496	520	Alexa488, FITC, Cy2
PWE1122	Flamma® 552 Amine	550	565	Alexa555, DyLight549, Cy3, ATTO550
KWE1415	Flamma® 581 Amine	578	593	Alexa594, DyLight594
PWE1215	Flamma® 648 Amine	648	663	Alexa647, DyLight650, Cy5
PWE1515	Flamma® 675 Amine	675	691	Alexa680, DyLight680, Cy5.5, IRDye680LT, CF680
PWE1301	Flamma® 749 Amine	749	774	Alexa750, DyLight755, Cy7.5, IRDye750
PWE1603	Flamma® 774 Amine	774	800	Cy7.5, DyLight800, IRDye800

Flamma® Fluors Thiol
496	552	581	648	675	749	774



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
CWT1001	Flamma® 496 Thiol	494	520	Alexa488, FITC, Cy2
CWT1058	Flamma® 552 Thiol	550	564	Alexa555, DyLight549, Cy3, ATTO550
KWT1415	Flamma® 581 Thiol	578	593	Alexa594, DyLight594
KWT1042	Flamma® 648 Thiol	648	663	Alexa647, DyLight650, Cy5
PWT1415	Flamma® 675 Thiol	674	691	Alexa680, DyLight680, Cy5.5, IRDye680LT, CF680
PWT1215	Flamma® 749 Thiol	749	774	Alexa750, DyLight755, Cy7.5, IRDye750
PWT1515	Flamma® 774 Thiol	774	800	Cy7.5, DyLight800, IRDye800

Flamma® Fluors Alkyne
496	552	581	648	675	749	774



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
CWK1001	Flamma® 496 Alkyne	496	520	Alexa488, FITC, Cy2
PWK1122	Flamma® 552 Alkyne	550	564	Alexa555, DyLight549, Cy3, ATTO550
KWK1415	Flamma® 581 Alkyne	581	596	Alexa594, DyLight594
PWK1215	Flamma® 648 Alkyne	648	663	Alexa647, DyLight650, Cy5
PWK1515	Flamma® 675 Alkyne	674	691	Alexa680, DyLight680, Cy5.5, IRDye680LT
PWK1301	Flamma® 749 Alkyne	749	774	Alexa750, DyLight755, Cy7.5, IRDye750
PWK1603	Flamma® 774 Alkyne	774	800	Cy7.5, DyLight800, IRDye800

Flamma® Fluors PEG4-Alkyne
496	552	581	648	675	749	774



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
CWG1001	Flamma® 496 PEG4-Alkyne	496	520	Alexa488, FITC, Cy2
PWG1122	Flamma® 552 PEG4-Alkyne	550	564	Alexa555, DyLight549, Cy3, ATTO550
KWG1415	Flamma® 581 PEG4-Alkyne	581	596	Alexa594, DyLight594
PWG1215	Flamma® 648 PEG4-Alkyne	648	663	Alexa647, DyLight650, Cy5
PWG1515	Flamma® 675 PEG4-Alkyne	674	691	Alexa680, DyLight680, Cy5.5, IRDye680LT
PWG1301	Flamma® 749 PEG4-Alkyne	749	774	Alexa750, DyLight755, Cy7.5, IRDye750
PWG1603	Flamma® 774 PEG4-Alkyne	774	800	Cy7.5, DyLight800, IRDye800

Flamma® Fluors ADIBO
496	552	581	648	675	749	774



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
DWC1001	Flamma® 496 ADIBO	496	520	Alexa488, FITC, Cy2
DWC1011	Flamma® 552 ADIBO	550	564	Alexa555, DyLight549, Cy3, ATTO550
DWC1415	Flamma® 581 ADIBO	581	596	Alexa594, DyLight594
DWC1021	Flamma® 648 ADIBO	648	663	Alexa647, DyLight650, Cy5
DWC1051	Flamma® 675 ADIBO	674	691	Alexa680, DyLight680, Cy5.5, IRDye680LT
DWC1031	Flamma® 749 ADIBO	749	774	Alexa750, DyLight755, Cy7.5, IRDye750
DWC1061	Flamma® 774 ADIBO	774	800	Cy7.5, DyLight800, IRDye800

Flamma® Fluors Azide
496	552	581	648	675	749	774



Quick link (Cat.#)	FSD series	EXmax (nm)	EMmax (nm)	Spectrally similar dyes
CWZ1001	Flamma® 496 Azide	496	520	Alexa488, FITC, Cy2
PWZ1122	Flamma® 552 Azide	550	564	Alexa555, DyLight549, Cy3, ATTO550
KWZ1415	Flamma® 581 Azide	581	596	Alexa594, DyLight594
PWZ1215	Flamma® 648 Azide	648	663	Alexa647, DyLight650, Cy5
PWZ1515	Flamma® 675 Azide	674	691	Alexa680, DyLight680, Cy5.5, IRDye680LT
PWZ1301	Flamma® 749 Azide	749	774	Alexa750, DyLight755, Cy7.5, IRDye750
PWZ1603	Flamma® 774 Azide	774	800	Cy7.5, DyLight800, IRDye800
