5 Part Auto Hematology Analyzer (BH-HA650)
5 Part Auto Hematology Analyzer (BH-HA650)
Cat. No. DCBio-BH-HA650
Features
- Throughput 70t/h.
- 14 inch touch screen.
- 50 sample positions, automatic loading, mixing and sampling.
- Tri-angle laser scatter + flow cytometry method + impedance method for RBC and PLT counting.
- 3D holographic scattergram displays the accurate 5 part differentiation of WBC.
- Large storage capacity: 100,000 results(including histogram, scattergram, patient information).
- 50 Flags including MALARIA and DENGUE Flags to help analysis results.
Model
|
Model |
DCBio-BH-HA650 |
|||
|
Throughput |
70 tests/hour |
|||
|
Assay Items |
5 parts, 25 parameters, 3 histograms(WBC/BASO, RBC, PLT), 3D scattergram |
|||
|
Principle |
Tri-angle laser scatter, Flow cytometry method, 3D scattergram analysis, Impedance method for RBC and PLT counting, Cyanide-free method for HGB test |
|||
|
Test mode |
CBC mode, CBC+DIFF mode Venous whole blood, Capillary whole blood and Prediluted |
|||
|
Sample Modes |
CBC+DIFF mode: ≤20μl |
|||
|
CBC mode: ≤10μl |
||||
|
Parameters |
25 reportable parameters: WBC, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, 6 research parameters: ALY%, ALY#, LIC%, LIC#, NRBC%, NRBC# |
|||
|
Performance |
Item |
Linear range |
Carry over |
CV |
|
WBC |
0~300.0*10^9/L |
≤0.5% |
≤2.0% |
|
|
RBC |
0~8.00*10^12/L |
≤0.5% |
≤1.5% |
|
|
HGB |
0~250g/L |
≤0.5% |
≤1.5% |
|
|
PLT |
0~3000*10^9/L |
≤1.0% |
≤4.0% |
|
|
Storage |
Up to 100,000 results including histograms, scattergrams and patient information |
|||
|
Display |
14 inch touch screen, resolution 1366*768 |
|||
|
Interface |
4 USB ports, 1 LAN port, Bi-direction LIS, support HL7 protocol, Internal RFID reader |
|||
|
Loading Position |
50 sample positions |
|||
|
Power supply |
AC100~240V, 50/60Hz; 300VA |
|||
|
Package Size |
Main Machine: 680*580*895mm Accessories: 950*500*580mm |
|||
|
Gross Weight |
Main Machine: 60kg/ 132.3lb Accessories: 27.6kg/ 60.8lb |
|||
|
Reagent Package Size |
330*330*330mm (W*D*H);400*290*240mm (W*D*H); 400*290*240mm (W*D*H) |
|||
|
Reagent Gross Weight |
22kg; 2kg; 1kg |
|||
Note: This product weighs over 50 pounds and requires a liftgate truck for delivery. However, if you have a loading dock for delivery trucks, a liftgate truck may not be necessary. For more information, click here >>> go or refer to the FedEx website >>> go.
