Cell Structure Analysis

Product#: DC-Cell-Structure-Analysis
$0.00

Select BIOACT5

  • Check below icons

Availability:
Ships in 24 hours

Some of items are currently out of stock. Please submit an inquiry if you would like to check availability or make a purchase

Inquire about the Item  to,   support@diagnocine.com

Cell Structure Analysis Probes




FSD Fluor™ Phalloidin Series

Phalloidin is a rigid bicyclic peptide toxin isolated from Amanita phalloides mushroom that commonly used in imaging applications to selective label F-actin. Phalloidin is known to react stoichiometrically with actin, strongly promote actin polymerization, and stabilize actin polymers. Due to the ability to bind F-actin selectively, fluorescence conjugated phalloidin derivatives are widely used in microscopy for investigating the distribution of F-actin in cells. In biomedical research, fluorescent phalloidin probes are utilized in localizing actin filaments in living or fixed cells as well as for visualizing individual actin filaments in vitro. Fluorescent phalloidins much smaller than fluorescent antibodies, thus they have several advantages for actin labeling such as virtually identical binding properties with actin from different species of plants and animals, much denser labeling of filamentous actin, more detailed images, and lower nonspecific binding. Fluorescent phalloidin conjugates are not permeable to most live cells, thus they should be used to detect cells with compromised membranes. However, fluorescent labeled phalloidins may penetrate the membranes of certain hypoxic cells. BioActs offers FSD Fluor™ Phalloidin series for the labeling and quantitative analysis of F-actin in formaldehyde-fixed and permeabilized tissue sections, cell cultures, and cell-free experiments.

CytoFlamma® Cell Membrane

Lipophilic organic dyes bear some structural resemblance to natural lipids and can be incorporated into cell wall and liposome. BioActs developed CytoFlamma® cell membrane series as versatile membrane selective fluorescent probes. The probes consist of Flamma dye attached with hydrophobic lipid analogs. They can be used in studies for biophysical analysis of membranes, for tracing lipid transport and metabolism in live cells, and for lipid-mediated signal transduction processes. Flamma® dyes display strong absorption, high fluorescence quantum yield and high photostability, and they maintain good fluorescence activity and stability after conjugation to biomolecules. Due to low toxicity and stable retention, CytoFlamma® cell membrane probes might be useful for long-term cell tracing and can be used as membrane markers of endocytosis and exocytosis. The probes are stable under photooxidation effects induced by ultraviolet excitation and are resistant to spontaneous oxidation. We offer CytoFlamma® cell membrane series as selective fluorescent probes for analyzing cell structure by incorporating into plasma membrane.

MitoFlamma® Green

MitoFlamma® Green is a mitochondria-selective green fluorescent dye that allows to detect mitochondrial morphology in living cells. This unique dye appears to preferentially accumulate in mitochondria regardless of mitochondrial membrane potential in certain cell types, making it a possible tool for determining mitochondrial mass. MitoFlamma® Green enables researchers to observe mitochondrial activity, localization and abundance as well as monitoring the effect of drugs or other external stimuli on the mitochondrial function. The maxima of excitation/emission are at 508/580 nm. Once mitochondria are labeled with this special dye, the cells can be treated with an aldehyde fixative for samples that require fixation for further processing. MitoFlamma® Green probes are retained in the mitochondria during the fixation step and after permeabilization with some detergents during subsequent processing steps. After fixation, labeled samples can be applied in a variety of experiments such as immunocytochemistry, in situ hybridization, microplate-based analysis, etc.

Cytoskeleton


Diagnocine-F1.png Diagnocine-F1.png Diagnocine-F1.png Diagnocine-F1.png Diagnocine-F1.png Diagnocine-F1.png Diagnocine-F1.png
496/519  555/565 593/618 651/667 679/696 751/774  774/790

Table 1. List of FSD Fluor™ Phalloidin

Quick link (Cat.#) Series λEx (nm) λEm (nm) Packing unit
RCS2114 FSD Fluor™ 488 Phalloidin 495 519 300 tests
RCS2214 FSD Fluor™ 555 Phalloidin 554 565 300 tests
RCS2314 FSD Fluor™ 594 Phalloidin 593 618 300 tests
RCS2414 FSD Fluor™ 647 Phalloidin 651 667 300 tests
RCS2514 FSD Fluor™ 680 Phalloidin 679 696 300 tests
RCS2614 FSD Fluor™ 750 Phalloidin 751 774 300 tests
RCS2714 FSD Fluor™ 800 Phalloidin 774 790 300 tests


Plasma Membrane

Diagnocine-F1.png Diagnocine-F1.png Diagnocine-F1.png Diagnocine-F1.png Diagnocine-F1.png Diagnocine-F1.png
549/564 (1 mM) 549/564 (5 mM)  648/672 (1 mM) 648/672 (5 mM) 756/785 (1 mM) 756/785 (5 mM)

Table 2. List of CytoFlamma® cell membrane

Quick link (Cat.#) Series λEx (nm) λEm (nm) Packing unit
RCS1322 CytoFlamma® 552 Cell-membrane (1 mM) 549 564 1 mL
RCS1323 CytoFlamma® 552 Cell-membrane (5 mM) 549 564 1 mL
RCS1422 CytoFlamma® 648 Cell-membrane (1 mM) 648 672 1 mL
RCS1423 CytoFlamma® 648 Cell-membrane (5 mM) 648 672 1 mL
RCS1622 CytoFlamma® 749 Cell-membrane (1 mM) 756 785 1 mL
RCS1623 CytoFlamma® 749 Cell-membrane (5 mM) 756 785 1 mL

Mitochondria

498/583

Table 3. MitoFlamma® Green

Quick link (Cat.#) Series λEx (nm) λEm (nm) Packing unit
RMS1101 MitoFlamma® Green (live) 498 583 100 tests
