NEXTY-S Single Channel Pipette

Cat.No: WBSCP
1pc/box each

Watson Bio® GMP System

7 models of “NEXTY-S”  single channel pipettes
to cover the full volume range from 0.2µL to 5000µL!

Does your pipette fit your hand?

The hand grip of a pipette should fit the user’s hand. After all, human hands come in assorted shapes and sizes, so a pipette’s hand grip needs to accommodate various forms.

An ergonomic design of this part of the pipette is crucial for stress-free working hours. Ejector button and finger hook needs to be in comfortable reach for your fingers.

Slim Body, Easy to Grasp

Thanks to its slim body, those who have small hands can easily grasp it, and it realizes stable dispensing.

Triple Speed Turbo Dial 1 rotation of triple turbo dial is equal to 3.5 rotations of the push-button dial. Quite speedy even when making large volume changes.	Light stroke, Less Fatigue Light stroke and easy handling reduce repetitive stress on the thumb.

■ Autoclavable bottom parts
	The nozzle cone and eject cone can be taken off and autoclaved. *O-rings and seal rings can be left in nozzle cone - they are autoclavable. The nozzle cone can be autoclaved as well. Nozzle cone can be autoclaved with together them.
■ Color-coded
	NEXTY’s push button has different color by each maximum volume.
■ Tip fitting ribs (NT-S1000,NT-S5000 only.)
The NT-S10000 and NT-S5000 pipettes are equipped with special chaped (ribbed) nozzle cones, which provide good and soft tip fitting. *NT-S5000 must be used with Watson 5mL tips.

7 models of “NEXTY-S”  single channel pipettes to cover the full volume range from 0.2µL to 5000µL!

Cat. No.	Item	Minimal Scale	Volume	Accuracy	Precision	Compatible Tip
WBNT-S2	NEXTY Single Channel Pipette 0.2 – 2 µL	0.001 µL	0.2 µL	±15.0%	≤8.0%	204/207
			2 µL	±2.5%	≤1.0%
WBNT-S10	NEXTY Single Channel Pipette 1 – 10 µL	0.01 µL	1  µL	±5.0%	≤2.5%	204/207
			10 µL	±1.0%	≤0.5%
WBNT-S20	NEXTY Single Channel Pipette 2 – 20 µL	0.01 µL	2 µL	±6.0%	≤3.0%	705/703/503
			20 µL	±1.0%	≤0.5%
WBNT-S100	NEXTY Single Channel Pipette 10 – 100 µL	0.1 µL	10 µL	±2.0%	≤1.0%	705/703/503 505/801
			100 µL	±0.8%	≤0.3%
WBNT-S200	NEXTY Single Channel Pipette 20 – 200 µL	0.1 µL	20 µL	±2.0%	≤1.0%	705/703/503 505/801
			200 µL	±0.8%	≤0.3%
WBNT-S1000	NEXTY Single Channel Pipette 100 – 1000 µL	1 µL	100 µL	±2.0%	≤0.6%	502/706/804 806/805
			1000 µL	±0.8%	≤0.3%
WBNT-S5000	NEXTY Single Channel Pipette 500 – 5000 µL	5 µL	500 µL	±2.0%	≤0.6%	401
			5000 µL	±0.8%	≤0.3%

Each pipette is calibrated with a tip in bold letter shown above. Other tips if used may cause a slight deviation in performance.


Watson Bio®  Quality Control


The product that adheres this mark is RNase/DNase/Human-DNA FREE.

Fukae / Watson products are produced in a clean room production line where original Watson's strict system of the quality is set up. These products are inspected by rigorous quality standards, and we will issue the RNase / DNase certificate of each lot at your request.

The product that adheres this mark is Pyrogen FREE.

This mark shows endotoxin level reach 0.05 EU/mL or less when our products were tested using a colorimetric method based on the Japanese Pharmacopoeia.

Severe system of quality control

A strict system of the quality check is set up in each place in the manufacturing process, and the inspection with a microscope and a profile projector, etc. is executed at any time.

Only the products that fills rigorous quality standards is sent off to the world. This is the proof of the trust of Watson brand.

Clean room environment

Our facilities include a CleanRoom to fulfill the requirements of RNase / DNase FREE and also Endotoxin FREE environment. Only the special skilled staff with protective suits are allowed to enter our clean room.

Quality Control Structure

Fukae-Kasei maintains a thorough quality control structure. Products are checked at each of the manufacturing processes with various measuring devices.

Only those produced goods that meet the strict quality standards will be released as products.
